OPENWORKED TOURBILLON

These two new creations vividly illustrate the quintessential charm of fine watchmaking according to Speake-Marin: the relentless pursuit of an ideal that is both physical and aesthetic, designed to ensure that mechanical movement never deviates from the onward march of time. Enter the two new Openworked Tourbillon models.

Specification SM3

Casing-diameter
  • 30.00 mm
Height (without hands)
  • 5.40 mm
Kind of winding
  • Automatic
Frequency
  • 3 Hz (21'600A/h)
Number of jewels
  • 25
Number of components
  • 192
Power reserve
  • 72 h
Angle of lift
  • 52°
Warranty
  • 2+ 2 years*

Specification VALJOUX 88

Casing-diameter
  • 29.50 mm
Height (without hands)
  • 7.2 mm
Kind of winding
  • Manual
Frequency
  • 2.5 Hz (18'00A/h)
Power reserve
  • 40 hours
Angle of lift
  • 49 to 53°
Warranty
  • 2+ 2 years*

Specification VALJOUX 72

Casing-diameter
  • 29.50 mm
Height (without hands)
  • 7.33 mm
Kind of winding
  • Manual
Frequency
  • 2.5 Hz (18'00A/h)
Power reserve
  • 40 hours
Angle of lift
  • 49 to 53°
Warranty
  • 2+ 2 years*

Specification SMA HH-02 MOVEMENT

Casing-diameter
  • 34.40mm
Height (without hands)
  • 9.80mm
Kind of winding
  • Manual
Frequency
  • 3 Hz (21'600 A/h)
Power reserve
  • 72 hours
Number of jewels
  • 51
Number of components
  • 536
Angle of lift
  • 52°
Winding by the winding-stem
  • 33 tours
Warranty
  • 2+ 2 years*

Specification SMA HH-06 MOVEMENT

Casing-diameter
  • 38.00mm
Height (without hands)
  • 8.75mm
Kind of winding
  • Manual
Frequency
  • 3 Hz (21'600 A/h)
Power reserve
  • 72 hours
Number of jewels
  • 56
Number of components
  • 402
Angle of lift
  • 52°
Winding by the winding-stem
  • 33 tours
Warranty
  • 2+ 2 years*

Specification SMA01 MOVEMENT

Casing-diameter
  • 30.00mm
Height (without hands)
  • 5.00mm
Kind of winding
  • Automatic
Frequency
  • 4 Hz (28'800 A/h)
Power reserve
  • 52 hours
Number of jewels
  • 33
Number of components
  • 171
Angle of lift
  • 51°
Average rate
  • Criteria COSC
Winding by the winding-stem
  • 192 tours
Warranty
  • 2+ 2 years*

Specification MOVEMENT SMA03-T 2023

Casing-diameter
  • 30.00mm
Height (without hands)
  • 3.9 mm
Kind of winding
  • Automatic
Frequency
  • 4 Hz (28'800 A/h)
Power reserve
  • 52 hours
Number of jewels
  • 31
Number of components
  • 144
Angle of lift
  • 51°
Average rate
  • 5 ± 5 s/d
Winding by the winding-stem
  • 192 tours
Warranty
  • 2+ 2years*

Specification MOVEMENT SMA05

Casing-diameter
  • 34.00mm
Height (without hands)
  • 7.15 mm
Kind of winding
  • Automatic
Frequency
  • 3 Hz (21'600A/h)
Power reserve
  • 72 hours
Number of jewels
  • 33
Number of components
  • 290
Angle of lift
  • 52°
Average rate
  • 4 ± 4 s/d
Winding by the winding-stem
  • 192 tours
Warranty
  • 2+ 2years*

Specification MOVEMENT SMA03-TD

Casing-diameter
  • 30.00mm
Height (without hands)
  • 3.9 mm
Kind of winding
  • Automatic
Frequency
  • 4 Hz (28'800 A/h)
Power reserve
  • 52 hours
Number of jewels
  • 31
Number of components
  • 162
Angle of lift
  • 51°
Average rate
  • 5 ± 5 s/d
Winding by the winding-stem
  • 192 tours
Warranty
  • 2+ 2years*

Specification MOVEMENT SMA03-T20

Casing-diameter
  • 30.00mm
Height (without hands)
  • 3.9 mm
Kind of winding
  • Automatic
Frequency
  • 4 Hz (28'800 A/h)
Power reserve
  • 52 hours
Number of jewels
  • 31
Number of components
  • 145
Angle of lift
  • 51°
Average rate
  • 5 ± 5 s/d
Winding by the winding-stem
  • 192 tours
Warranty
  • 2+ 2years*

Specification MOVEMENT SMA05

Casing-diameter
  • 34.00mm
Height (without hands)
  • 7.15 mm
Kind of winding
  • Automatic
Frequency
  • 3 Hz (21'600A/h)
Power reserve
  • 72 hours
Number of jewels
  • 33
Number of components
  • 290
Angle of lift
  • 52°
Average rate
  • 4 ± 4 s/d
Winding by the winding-stem
  • 192 tours
Warranty
  • 2+ 2years*

Specification MOVEMENT SMA03-T

Casing-diameter
  • 30.00mm
Height (without hands)
  • 3.9 mm
Kind of winding
  • Automatic
Frequency
  • 4 Hz (28'800 A/h)
Power reserve
  • 52 hours
Number of jewels
  • 29
Number of components
  • 147
Angle of lift
  • 51°
Average rate
  • 5 ± 5 s/d
Winding by the winding-stem
  • 192 tours
Warranty
  • 2+ 2years*

Specification MOVEMENT SMA03

Casing-diameter
  • 30.00mm
Height (without hands)
  • 3.9 mm
Kind of winding
  • Automatic
Frequency
  • 4 Hz (28'800 A/h)
Power reserve
  • 52 hours
Number of jewels
  • 31
Number of components
  • 147
Angle of lift
  • 51°
Average rate
  • 5 ± 5 s/d
Winding by the winding-stem
  • 192 tours
Warranty
  • 2+ 2years*

Specification MOVEMENT SMA02

Casing-diameter
  • 34.00mm
Height (without hands)
  • 6.65 mm
Kind of winding
  • Automatic
Frequency
  • 4 Hz (28'800 A/h)
Power reserve
  • 52 hours
Number of jewels
  • 36
Number of components
  • 273
Angle of lift
  • 51°
Average rate
  • 5 ± 5 s/d
Winding by the winding-stem
  • 192 tours
Warranty
  • 2+ 2years*
