Specification SMA HH-02 MOVEMENT

Casing-diameter
  • 34.40mm
Height (without hands)
  • 9.80mm
Kind of winding
  • Manual
Frequency
  • 3 Hz (21'600 A/h)
Power reserve
  • 72 hours
Number of jewels
  • 51
Number of components
  • 536
Angle of lift
  • 52°
Winding by the winding-stem
  • 33 tours
Warranty
  • 2+ 2 years*

Specification SMA HH-06 MOVEMENT

Casing-diameter
  • 38.00mm
Height (without hands)
  • 8.75mm
Kind of winding
  • Manual
Frequency
  • 3 Hz (21'600 A/h)
Power reserve
  • 72 hours
Number of jewels
  • 56
Number of components
  • 402
Angle of lift
  • 52°
Winding by the winding-stem
  • 33 tours
Warranty
  • 2+ 2 years*

Specification SMA01 MOVEMENT

Casing-diameter
  • 30.00mm
Height (without hands)
  • 5.00mm
Kind of winding
  • Automatic
Frequency
  • 4 Hz (28'800 A/h)
Power reserve
  • 52 hours
Number of jewels
  • 33
Number of components
  • 171
Angle of lift
  • 51°
Average rate
  • Criteria COSC
Winding by the winding-stem
  • 192 tours
Warranty
  • 2+ 2 years*

Specification MOVEMENT SMA05

Casing-diameter
  • 34.00mm
Height (without hands)
  • 7.15 mm
Kind of winding
  • Automatic
Frequency
  • 3 Hz (21'600A/h)
Power reserve
  • 72 hours
Number of jewels
  • 33
Number of components
  • 290
Angle of lift
  • 52°
Average rate
  • 4 ± 4 s/d
Winding by the winding-stem
  • 192 tours
Warranty
  • 2+ 2years*

Specification MOVEMENT SMA03-TD

Casing-diameter
  • 30.00mm
Height (without hands)
  • 3.9 mm
Kind of winding
  • Automatic
Frequency
  • 4 Hz (28'800 A/h)
Power reserve
  • 52 hours
Number of jewels
  • 31
Number of components
  • 166
Angle of lift
  • 51°
Average rate
  • 5 ± 5 s/d
Winding by the winding-stem
  • 192 tours
Warranty
  • 2+ 2years*

Specification MOVEMENT SMA03-T20

Casing-diameter
  • 30.00mm
Height (without hands)
  • 3.9 mm
Kind of winding
  • Automatic
Frequency
  • 4 Hz (28'800 A/h)
Power reserve
  • 52 hours
Number of jewels
  • 31
Number of components
  • 145
Angle of lift
  • 51°
Average rate
  • 5 ± 5 s/d
Winding by the winding-stem
  • 192 tours
Warranty
  • 2+ 2years*

Specification MOVEMENT SMA05

Casing-diameter
  • 34.00mm
Height (without hands)
  • 7.15 mm
Kind of winding
  • Automatic
Frequency
  • 3 Hz (21'600A/h)
Power reserve
  • 72 hours
Number of jewels
  • 33
Number of components
  • 290
Angle of lift
  • 52°
Average rate
  • 4 ± 4 s/d
Winding by the winding-stem
  • 192 tours
Warranty
  • 2+ 2years*

Specification MOVEMENT SMA03-T

Casing-diameter
  • 30.00mm
Height (without hands)
  • 3.9 mm
Kind of winding
  • Automatic
Frequency
  • 4 Hz (28'800 A/h)
Power reserve
  • 52 hours
Number of jewels
  • 29
Number of components
  • 147
Angle of lift
  • 51°
Average rate
  • 5 ± 5 s/d
Winding by the winding-stem
  • 192 tours
Warranty
  • 2+ 2years*

Specification MOVEMENT SMA03

Casing-diameter
  • 30.00mm
Height (without hands)
  • 3.9 mm
Kind of winding
  • Automatic
Frequency
  • 4 Hz (28'800 A/h)
Power reserve
  • 52 hours
Number of jewels
  • 31
Number of components
  • 147
Angle of lift
  • 51°
Average rate
  • 5 ± 5 s/d
Winding by the winding-stem
  • 192 tours
Warranty
  • 2+ 2years*

Specification MOVEMENT SMA02

Casing-diameter
  • 34.00mm
Height (without hands)
  • 6.65 mm
Kind of winding
  • Automatic
Frequency
  • 4 Hz (28'800 A/h)
Power reserve
  • 52 hours
Number of jewels
  • 36
Number of components
  • 273
Angle of lift
  • 51°
Average rate
  • 5 ± 5 s/d
Winding by the winding-stem
  • 192 tours
Warranty
  • 2+ 2years*
